Lock with Pyramid
PART # S498-P
The ALPS Lock with Pyramid is an all-in-one lock body design which combines the lock and pyramid.
The glass reinforced nylon lock body exhibits better wear characteristics than delrin or aluminum.
The convenient one-way gear allows the user to push in or wind out the limb into the prosthetic socket.
A unique feature of this lock is that if foreign material or clothing get caught in the gear, the housing can be removed, freeing the pin.
KEY BENEFITS
For laminated sockets
All-in-one lock body design combining the lock and pyramid
Infinite pin adjustment reduces play
The housing can be removed, freeing the pin
100 kg (220 lbs) weight rating
Lock with Pyramid part number and spare parts.
| SPARE PARTS | DESCRIPTION |
|---|---|
| S498-P | Main body with pyramid |
| LDH - 694 A | Locking mechanism |
| LDP - 695 | Serrated pin |
| LDA - 694 | Hex nut adaptor dummy |
