ALPS Extreme™ Liner HD Gel
PART # AKDTHD/AKFRHD
ALPS Extreme HD is a prosthetic liner made of High-Density Gel that provides a high level of comfort and superior protection of the residual limb, even for more active users.
It is indicated for patients with medium and high activity levels as it offers a high level of control while preserving comfort. It is also recommended for patients whose residual limbs have excessive soft tissue and transfemoral amputees.
Product Description
ALPS Extreme prosthetic liner, in its HD Gel version, provides the patient with comfort and control.
The fabric, with its limited vertical elongation, further limits vertical pistoning.
The HD Gel relieves the residual limb from vertical and shear forces; at the same time, it makes the liner more compact.
This makes it an ideal liner for the most active users who are looking to maintain maximum control of the prosthetic leg without compromising comfort.
KEY BENEFITS
Reduces pistoning thanks to the fabric's limited vertical stretch and the distal matrix (locking version).
Minimizes the movement of soft tissue and provides a high level of control of the prosthetic leg by combining the properties of the High Density Gel with those of the limited vertical stretch fabric.
Protects the residual limb thanks to the high capacity of the HD Gel to absorb vertical and shear forces.
Technical Details
MATERIAL | HIGH DENSITY GEL
AMPUTATION LEVEL
ACTIVITY LEVEL
THICKNESS
SUSPENSION
FABRIC | BROWN
Extreme Liner AKDTHD/AKFRHD Sizing Chart
Measure the circumference of the stump at 6 cm above the distal end.
| MEASURED SIZE (CM) | LOCKING 3MM OR 6MM UNIFORM | CUSHION 3MM OR 6MM UNIFORM |
|---|---|---|
| 16-19 cm | AKDTHD16-(3 or 6) | AKFRHD16-(3 or 6) |
| 20-23 cm | AKDTHD20-(3 or 6) | AKFRHD20-(3 or 6) |
| 24-25 cm | AKDTHD24-(3 or 6) | AKFRHD24-(3 or 6) |
| 26-27 cm | AKDTHD26-(3 or 6) | AKFRHD26-(3 or 6) |
| 28-31 cm | AKDTHD28-(3 or 6) | AKFRHD28-(3 or 6) |
| 32-34 cm | AKDTHD32-(3 or 6) | AKFRHD32-(3 or 6) |
| 35-37 cm | AKDTHD35-(3 or 6) | AKFRHD35-(3 or 6) |
| 38-43 cm | AKDTHD38-(3 or 6) | AKFRHD38-(3 or 6) |
| 44-53 cm | AKDTHD44-(3 or 6) | AKFRHD44-(3 or 6) |
Distal End Construction
The Extreme Liner's distal end assembly process is unique and complex, involving several elements that fuse together to create a highly durable internal structure. This structure results in a liner that is guaranteed to provide the protection, comfort, durability, performance, and fit that users deserve.
