ALPS® Superior Performance HD Liner
PART # SPDTHD/SPFRHD
ALPS Superior Performance HD is a prosthetic liner made of High-Density Gel that provides even the most active users maximum protection of the residual limb.
It is indicated for patients with medium and high activity levels who require both comfort and elevated levels of control of the prosthetic leg. It is also recommended for patients whose residual limbs have excessive soft tissue and transfemoral amputees.
PRODUCT DESCRIPTION
GEL TECHNOLOGY
The HD Gel relieves the residual limb from vertical and shear forces; at the same time, it makes the liner more compact.
FABRIC TECHNOLOGY
With its limited vertical elongation, the fabric further limits the vertical pistoning.
LOCKING & CUSHION SUSPENSION
The locking version features a Reinforced Matrix to prevent distal pistoning and contain redundant tissue.
KEY BENEFITS
Reduces pistoning thanks to the fabric's limited vertical stretch and the distal matrix (locking version).
Minimizes the movement of soft tissue and provides a high level of control of the prosthetic leg by combining the properties of the High Density Gel with those of the limited vertical stretch fabric.
Protects the residual limb thanks to the high capacity of the HD Gel to absorb vertical and shear forces.
TECHNICAL DETAILS
MATERIAL | HIGH DENSITY GEL
AMPUTATION LEVEL
ACTIVITY LEVEL
THICKNESS
SUSPENSION
FABRIC | BLACK
Superior Performance Liner SPDTHD/SPFRHD Sizing Chart
Measure the circumference of the residual limb at 6 cm above the distal end.
| MEASURED SIZE (CM) | LOCKING 3MM OR 6MM UNIFORM | CUSHION 3MM OR 6MM UNIFORM |
|---|---|---|
| 16-19 cm | SPDTHD16-(3 or 6) | SPFR16HD-(3 or 6) |
| 20-23 cm | SPDTHD20-(3 or 6) | SPFRHD20-(3 or 6) |
| 24-25 cm | SPDTHD24-(3 or 6) | SPFRHD24-(3 or 6) |
| 26-27 cm | SPDTHD26-(3 or 6) | SPFRHD26-(3 or 6) |
| 28-31 cm | SPDTHD28-(3 or 6) | SPFRHD28-(3 or 6) |
| 32-34 cm | SPDTHD32-(3 or 6) | SPFRHD32-(3 or 6) |
| 35-37 cm | SPDTHD35-(3 or 6) | SPFRHD35-(3 or 6) |
| 38-43 cm | SPDTHD38-(3 or 6) | SPFRHD38-(3 or 6) |
| 44-53 cm | SPDTHD44-(3 or 6) | SPFRHD44-(3 or 6) |
Distal End Construction
The Superior Performance distal end assembly process is unique and complex, involving several elements that fuse together to create a highly durable internal structure. This structure results in a liner that is guaranteed to provide the protection, comfort, durability, performance, and fit that users deserve.
